| Connectivity |
RF- Radio frequency input |
1 |
| AV input |
1 |
| USB interface type 2.0 (Qty / List ….) |
2 / USB 1, USB 2 |
| Optical digital audio output (SPDIF) |
1 |
| Earphone jack |
1 |
| HDMI ports |
HDMI inputs |
2 |
| HDMI type 1.4 with HDCP version 1.4 |
Yes |
| Analogue TV reception |
Colour-Sound systems in VHF band |
|
PAL/SECAM NTSC、(B/G,D/K,I ,M) |
| Colour-Sound systems in UHF band |
|
PAL/SECAM NTSC、(B/G,D/K,I ,M) |
| Image processing |
Backlight control |
No |
| Zoom function settings ( 4:3 / 16:9 / Auto / Zoom 1 / Zoom 2) |
Yes / Yes / Yes / Yes / Yes |
| 1:1 Pixel mapping |
Yes |
| Sound |
Audio power output per channel |
Watt |
6 |
| Number of speakers (Tweeter / Midrange / Woofer) |
0 / 2 / 0 |
| Automatic volume level (AVL) |
Yes |
| Audio equalizer |
Yes |
| Dolby Digital |
Yes |
| Audio enhancement -Type {SRS, BBE, SAP, DBX-TV….} |
SWS(hisilicon) |
| Lip-sync adjustment |
NO |
| Features |
On/off timer |
NO |
| Power off if no signal |
Yes |
| Sleep timer |
Yes |
| Program lock |
Yes |
| OSD transparency control |
No |
| Software version OSD indication |
Yes |
| Legal requirements: Disclaimer / Acceptance of Terms |
No / No |
| Favourite channels list |
Yes |
| Electronic point of sales (E-POS) |
No |
| OTA- Over the air software updates |
No |
| Voice command |
No |
| Screen mirroring {Miracast, Anyview Cast, …} |
No |
| Smartphone remote control application {TV remote, …} |
No |
| Replaceable demo video for Store mode |
No |
| Remote control via serial port |
No |
| USB media player |
Personal Video Recorder |
|
No |
| Time Shift |
|
No |
| DTV Recording (EPG scheduling / start from Standby ) |
|
No / No |
| DivX decoder |
|
No |
| MPEG4 (H.264) / H.265 decoder |
|
Yes / NO |
| DMP- Digital media player content (Music / Video / Photos / Text) |
|
Yes / Yes / Yes / Yes |
| DMP Auto-play |
|
No |
| DMP for UHD content via USB |
|
No |
| DMP File allocation table (FAT / FAT32 / exFAT / NTFS) |
|
Yes / Yes / No / Yes |
| PVR File allocation table (FAT / FAT32 / exFAT / NTFS) |
|
No / No / No / No |
| Hardware |
Processor / Cores |
|
Hi3731ARQCV1010D00 / 2 |
| Dual Tuner |
|
No |
| Colour (Front bezel, rear, stand) |
|
Black / Black / Black |
| Speakers mounted in a box |
|
Yes |
| Mains power switch |
|
No |
| Swivel base |
|
No |
| Compact packaging |
|
Yes |
| Supply range [Voltage / Frequency ] |
Volt / Hz |
100 ~ 240V / 50, 60Hz |
| Standby consumption |
Watt |
< 0.5W |
| Maximum time delay Power On to sound an image |
sec |
|
|
|
|
| Installation |
Stand area (Width / Depth) |
mm |
627/193 |
| Wall mount dimensions (Horiz x Vert) |
mm |
100 x 200 |
| Wall mount, screw thread |
mm |
M6, 12 |
| VESA compliance |
|
Yes |
| Detachable power cord |
|
No |
| Power cord length |
cm |
155 |
|
|
|
| Accessories |
Remote controller (Technology / Part number ) |
|
IR / EN-83801 |
| Battery (size / quantity) |
|
AAA / 2 |
| User manual / Quick setup guide |
|
1 / 1 |
| Warranty [In User manual | In separate sheet] |
|
In separate sheet |
| Skype camera (Qty / Part number) |
|
– |
| 3D glasses type [Passive | Shutter] / Link [RF | IR | BT] |
|
– |
| 3D glasses (Qty / Part number) |
|
– |
| Dimensions |
Dimensions with stand (W x H x D) |
mm |
730X479X193 |
| Dimensions without stand (W x H x D) |
mm |
730X432X72.8 |
| Carton box dimensions (W x H x D) |
mm |
826X523X317 |
| Net weight (with stand / without stand) |
kg |
3.9 / 4 |
| Gross weight |
kg |
6 |
| Container load (20ft / 40ft / 40ft HC) |
|
476/976/1220 |
